Technical Specifications
Engine Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder. EURO4 compliant.
Displacement 745cc
Bore & Stroke 77mm x 80mm
Compression Ratio 10.7 : 1
Max. Power Output 40.3kW @ 6,250rpm (95/1/EC)
Max. Torque 68Nm @ 4,750rpm (95/1/EC)
Oil Capacity MT : 3.7L, DCT : 4.1L
Fuel Tank Capacity 14.1 litres
Transmission Type MT: 6-speed Manual Transmission, DCT: 6-speed Dual Clutch Transmission
2230mm x 845mm x 1350mm
Wheelbase 1535mm
Seat Height 830mm
Ground Clearance 165 mm (minimum)
Kerb Weight MT: 220kg, DCT: 230kg
Suspension
Front 41mm telescopic fork, 153.5mm stroke
Rear Monoshock damper, Pro-Link swingarm, 150mm travel
Rim Size Front 17M/C x MT3.50
Rim Size Rear 17M/C x MT4.50
Tyres Front 120/70-ZR17M/C (58W)
Tyres Rear 160/60-ZR17M/C (69W)
Front Brake 320 mm single wavy hydraulic disc with 2-piston caliper and sintered metal pads
Rear Brake 240 mm single wavy hydraulic disc with single-piston caliper and resin mold pads
