  • Re: All YZF R15's engineered by Joel.

    Originally posted by stefanm View Post
    I have only done around 6k on the 180cc, as I don't ride in the rains and do a lot of short journeys, the 180cc is restricted without the big valves and larger tb, the 165cc had a lot more pep at higher revs, the 180cc however has become very smooth and less vibey of late, but still needs these mods, hopefully in the next few months i'll do, along with a new exhaust. I already have the Simota air filter, though the air box is not modded, not sure if that is required. My bike was also not running for three months, one month for some mods and perpetually waiting for parts from Yamaha, one month for painting and a month diagnosing and repairing busted starter clutch and starter motor, i think most guys have gone through the starter clutch getting busted if running a cam without decompression (whether from Joel or anywhere else), however I've been running a different map from Joel, which seems to have less stress/kickback on cold starts, which I figure will put less stress on the starter clutch. One thing I do for the first start of the day, is put the bike in 6th gear push back until it locks and press start (after returning to neutral) I am currently working on having a custom made spark plug wire and cap from the US, I think this will eliminate some of the niggling issues I have been having with cold starts, though at the moment things are ok, the spark plug cap is pretty crap, I am on my 3rd, I had replaced 2 during the 2k kms i had ridden whilst the bike was stock.
    Yep. Already on second starter motor :/
    Picturesque Bidar
    Mesmerizing Belum caves

    Second Chance-A trip to Kuntala Waterfalls, Sadarmatt Anicut,SriRamSagar Dam

    A 4 days rural Andhra exploration trip(Horsley hills,Gandikota)

    Independence Day ride: 6 Days exploration of less known Andhra

    My Bun Burner ride (Officially certified)

    Comment


    • Re: All YZF R15's engineered by Joel.

      ^^^ not had to change my starter motor till date. However, had to change the one way starter clutch once. I am a bit surprised that you had to change your starter motor. I though you were running a stock ECU. Most problems are due to the RD ECU, where the bike tends to reverse crank if it does not fire up in couple of tries.
      Only a biker knows why a dog sticks his head out of a car window.

      Multum in Parvo - Much in Little

      "Yes, it is FAST! No, you CAN'T ride it!" - http://www.xbhp.com/talkies/general-...a-300-san.html

      Comment


      • Re: All YZF R15's engineered by Joel.

        Went to Joels yesterday and changed the front sproket and made little taller. Now in 6th gear @4K rpm it does ~56kmph.. earlier it was doing ~50kmph. I suppose I can reach 150kmph ~11k rpm..

        I suppose there will loss of acceleration in 1st and 2nd as it is further taller but should be very little loss as the torque is very good in this set up..

        Will update u guys soon about that. Its hard for me to find time in my busy schedule.. untill then ride hard..
        Last edited by Sivasundaran; 05-01-2013, 12:40 PM.
        ----------------------------------------------------------------------
        Machines are meant to scream. Don't spoil her machinehood, red line her.

        Comment


        • Re: All YZF R15's engineered by Joel.

          Hi fellow hot-rodder's!

          Thank you all for your support and encouragement! We also apologize for all delays and issues you guys have
          faced with your orders upto now. As Race Concepts moves into a new phase of growth and development, there
          is a lot for you guys look forward to - Better products, faster delivery times and prompt customer support!

          Come June 1st 2013, please address all your queries to [email protected] and we will get back to you
          within 48 hours. Promise!

          Cheers and keep those engines revvin'!
          A good rider has balance, judgment, and good timing. So does a good lover!

          sigpic

          Comment


          • Re: All YZF R15's engineered by Joel.

            I think I am reviving a dead thread. Its important that misconception has to be cleared out. I can see people are comparing cast liner block to an all aluminium block. Steel liner should have cross hatch (honing) marks to retain the oil in the cylinder, where as Diasil has silicon embedded particles which doesnot have honing marks as with the liner based block. You can clearly see there is no honing marks in the Diasil cylinder, hence the bore will be shiny compared to iron sleeve block.

            Click image for larger version

Name:	img_6647.jpg
Views:	1
Size:	64.1 KB
ID:	1931863



            Click image for larger version

Name:	diasil-cylinder-forged-piston.jpg
Views:	1
Size:	94.9 KB
ID:	1931864

            Click image for larger version

Name:	P9300714.jpg
Views:	1
Size:	72.1 KB
ID:	1931865

            YAMAHA FZ150i ORIGINAL CYLINDER FULL SET RM500

            KJC là nền tảng giải trí trực tuyến tập hợp RR88, XX88, MM88 - 3 thương hiệu cá cược uy tín. Khuyến mãi hấp dẫn, tỷ lệ cược tốt nhất thị trường.


            According to Yamaha, both the piston and cylinder of YZF-R15 version 2.0 are made of all-aluminium and provide excellent heat dissipation. Its dissipation rate is three times better than steel. DiAsil cylinder also eliminates heat-induced engine power loss, and helps to improve fuel efficiency. Yamaha claims that the Die-cast Aluminium Silicon cylinder is given a special surface treatment to prevent oil evaporation from the cylinder’s surface and improves oil consumption. The Die-cast Aluminium Silicon cylinder also has excellent hardness quality and is considerably resistant to wear & tear as compared to conventional iron sleeves according to Yamaha.
            Last edited by vijaycool; 03-10-2016, 09:39 PM.
            https://www.facebook.com/TopCoatDetailersTCD/
            https://www.instagram.com/topcoat_detailers/

            Comment


            • Re: All YZF R15's engineered by Joel.

              Originally posted by vijaycool View Post
              I think I am reviving a dead thread. Its important that misconception has to be cleared out. I can see people are comparing cast liner block to an all aluminium block. Steel liner should have cross hatch (honing) marks to retain the oil in the cylinder, where as Diasil has silicon embedded particles which doesnot have honing marks as with the liner based block. You can clearly see there is no honing marks in the Diasil cylinder, hence the bore will be shiny compared to iron sleeve block.
              No point in rehashing things out here. The bottom line is this:

              The gentleman never provided the required support. He did not live up to the commitments made by him in terms of quality, performance & delivery of parts.

              The inevitable reason that the cast iron cylinders is being compared with hypereutectic aluminum cylinders is because the gentleman was supplying big bore cylinder which was basically a bored out stock cylinder with a press fit cast iron liner. He made certain claims for this part being as reliable and long lasting as stock cylinders which inevitably did not live up to the claims due various reasons.

              Don't get me wrong, I am aware of the pros and cons of both types of cylinders. It was a part of the learning experience. My personal experience with the gentleman's parts allowed me to learn a lot from the whole episode and I do not have any bitterness towards the whole thing.
              Only a biker knows why a dog sticks his head out of a car window.

              Multum in Parvo - Much in Little

              "Yes, it is FAST! No, you CAN'T ride it!" - http://www.xbhp.com/talkies/general-...a-300-san.html

              Comment


              • Re: All YZF R15's engineered by Joel.

                Originally posted by abhimanyu31 View Post
                No point in rehashing things out here. The bottom line is this:

                The gentleman never provided the required support. He did not live up to the commitments made by him in terms of quality, performance & delivery of parts.

                The inevitable reason that the cast iron cylinders is being compared with hypereutectic aluminum cylinders is because the gentleman was supplying big bore cylinder which was basically a bored out stock cylinder with a press fit cast iron liner. He made certain claims for this part being as reliable and long lasting as stock cylinders which inevitably did not live up to the claims due various reasons.

                Don't get me wrong, I am aware of the pros and cons of both types of cylinders. It was a part of the learning experience. My personal experience with the gentleman's parts allowed me to learn a lot from the whole episode and I do not have any bitterness towards the whole thing.
                Hi. I am not comparing kit provided by a particular supplier. People might confuse why their Diasil bores are shiny than regular steel liner bore and think that their bore is shot. So I have posted my findings which might be useful for the fellow members.
                https://www.facebook.com/TopCoatDetailersTCD/
                https://www.instagram.com/topcoat_detailers/

                Comment
